Anti Corrosive Pressure Transmitter


Overview of Anti Corrosive Pressure Transmitter

The RB21S is an anti-corrosive pressure transmitter built with special materials for applications where corrosion is a real concern. As a dependable Anti-corrosive Pressure Sensor, it uses a ceramic diaphragm sensing element together with a high-accuracy circuit board, all housed within PTFE wetted parts that stand up well to aggressive media. This careful choice of materials helps the device deliver steady, reliable readings even when it is in direct contact with harsh liquids. Its integrated construction and standard signal output make the RB21S easy and convenient to use right at the local working point, with minimal setup required. Working as a precise Anti-corrosive Pressure Transducer, it is well suited to pressure and level measurement of corrosive liquids across a range of demanding industries. Whether the job involves handling chemicals, treating wastewater, or monitoring difficult process fluids, RBA OPTISYNC PRIVATE LIMITED offers an anti-corrosive pressure measurement solution built for accuracy, durability, and dependable long-term performance.

Main Features

  • Integrated construction, unnecessary to do outer adjustment
  • High-performance ceramic sensing element
  • Resistance to strong acids, alkalis, and other highly corrosive liquids
  • Multi-protection design with enhanced durability
  • High reliability and stability

Applications

  • Chemical industry
  • Pharmaceutical industry
  • Water treatment industry
  • Oil and gas industry
  • Food and beverage industry
  • Laboratory and scientific research
Performance Characteristics
Pressure type Relative (gauged)
Compensated temperature range -20°~70° C
Measuring Range 0~0.3 ... 30 bar
Long term stability ≤±0.2 % FS/year
Accuracy ±0.25% FS/±0.5% FS
Response time <5 ms
Temperature coefficient <0.15 % FSR/10K, measuring span
<0.25 % FSR/10K, zero point -30° ... 80°C
Process pressure Refer measuring range for Process pressure
Connection variants G 1/4” or PG 1/2” Male thread
Application Temperature -10°~80°C
Material of Construction
Diaphragm Ceramic
Housing SS304
Wetted Parts PTFE
O ring FKM
Output Signal
Current output 4 ... 20 mA, 2-wire
Voltage output 0~5VDC
0~10VDC
0.5~4.5VDC
Power Supply
Voltage supply range 11 ... 30V DC, with 4 ... 20 mA output signal
15 ... 30V DC, with 0 ... 10V output signal
5V DC ratiometric ... with 0.5 ... 4.5V output signal
