AC Drive and VFD Supplier in Rajkot: Buying Guide

Key Takeaways

Rajkot units use VFDs on pump test benches, compressors, conveyors and machine tool spindles.
A VFD lets a pump test bench run the pump at different speeds without changing the motor.
Size the drive from the motor's rated current and the load type, then check panel heat and dust.
We supply Schneider Electric Altivar and Frecon drives to Rajkot from Ahmedabad.

In Rajkot the AC drive is as much a test tool as a control device. Pump makers use it to run a pump at different speeds on the test bench, machine tool builders use it on spindles, and every casting, forging and engineering plant has compressors, blowers and conveyors that work better with a controlled start. RB Automation is an AC drive and VFD supplier in Rajkot for Schneider Electric Altivar and Frecon drives. We supply them from Ahmedabad and help you size the drive to the motor and the load by phone, WhatsApp and email.

How a VFD Controls an AC Motor

A variable frequency drive rectifies the incoming supply and then builds a new output whose frequency and voltage it can vary. Because an induction motor's speed follows the supply frequency, the drive can start the motor gently, run it at any speed in its range and bring it to a controlled stop. It also protects the motor against overload, phase loss and similar faults. On centrifugal pumps and fans, slowing the motor instead of throttling the flow usually saves a large share of the power.

Drive Ranges We Supply to Rajkot

Schneider Electric Altivar

We are an authorised Schneider Electric partner. Our Altivar offer covers the low voltage drives (ATV12, ATV310 and ATV320, with built-in PID and Modbus) and the Altivar general purpose drives, which include the ATV61 for pump and fan duty and the Altivar Machine ATV320 for OEM machines. The Schneider AC drive overview has the full line-up.

Frecon

The FR01 smart inverter has a narrow book-type body for crowded panels. The FR150A and FR500A cover general machine and process duty, and the low power range serves small motors. The FR150T/FR500T is a solar water pump inverter with MPPT and dry-run protection, which is of interest to pump makers who also supply solar pumping systems. All Frecon models are listed under Frecon AC drives.

Sizing a VFD Step by Step

Read the nameplate: full-load amps first, then voltage and kW.
Know the load: pumps and fans are variable torque; conveyors, compressors and mixers need full torque at low speed and more overload margin.
Check the supply: single-phase or three-phase, and its voltage.
Decide the control: keypad, potentiometer, 4-20 mA or 0-10 V reference, digital inputs or Modbus from a PLC.
Plan stopping: heavy flywheels and quick stops can call for a braking resistor.
Look at the site: casting and grinding dust, summer heat inside the panel and long motor cables.

Where Rajkot Runs AC Drives

Pump and motor test benches at Metoda GIDC, Shapar-Veraval and Kuvadva: the drive sets the test speed while pressure transmitters and flow meters record the curve.

Machine tool builders in Aji GIDC and on Gondal Road: spindle speed control on lathes, drilling and tapping machines and SPMs.

Foundries and forging units: blowers, sand plant conveyors and compressors.

Morbi and Jetpur: fans, ball mill auxiliaries, conveyors and circulation pumps on ceramic and dyeing lines.

Keeping Drives Healthy in Dusty Plants

Rajkot's foundries and machine shops are hard on electronics. Most drive trips come from heat build-up, metal dust on heat sinks and loose power terminals rather than from a fault in the drive. Filtered ventilation, regular cleaning and saved parameter sets go a long way; our low voltage AC drive maintenance checklist lists the routine.

Drive Ranges and Where They Fit

Range	Brand	Good Rajkot fit
Altivar ATV12 / ATV310 / ATV320	Schneider Electric	Machine builders and plants standardised on Schneider
Altivar ATV61	Schneider Electric	Larger pumps, fans and high-torque process duty
FR01 smart inverter	Frecon	Crowded panels on compact machines
FR150A / FR500A	Frecon	Conveyors, compressors, test benches, general machines
Low power AC drives	Frecon	Small motors on SPMs and conveyors
FR150T / FR500T	Frecon	Solar water pumping systems

Matching the Drive to the Load

Rajkot load	Load type	What to watch
Centrifugal pump on a test bench	Variable torque	Smooth speed steps and a stable reference signal
Screw or reciprocating compressor	Constant torque	Overload margin for start under load
Sand plant or casting conveyor	Constant torque	Dust protection and start under full load
Machine tool spindle	Constant torque at low speed	Fast acceleration and possibly a braking resistor
Cooling or dust collection fan	Variable torque	Energy saving at reduced speed

A Typical VFD Application in Rajkot

Consider a typical pump performance test bench at Metoda GIDC. Without a drive, the test pump runs only at mains speed and each pump size needs a particular motor. With an AC drive feeding the test motor, the operator can bring the pump up gently, hold it at the rated speed or at a reduced speed, and step through test points while pressure transmitters and a flow meter log the readings to a PLC. A soft start also spares the bench pipework the shock of a direct-on-line start every few minutes, and the drive's own protection trips the motor if a pump seizes on test.

Common VFD Mistakes to Avoid

Choosing the drive from the kW figure and ignoring the motor's actual full-load current.
Installing drives in a foundry or grinding area with no dust filtering on the panel fans.
Running long motor cables to a test bench without checking the drive's cable length limits.
Expecting a heavy spindle to stop quickly without a braking resistor.
Never saving a copy of the drive parameters.

What to Send for an AC Drive Quote

A photo of the motor nameplate (kW, full-load current, voltage)
What the motor drives and how often it starts
Single-phase or three-phase supply
How speed will be set: keypad, potentiometer, 4-20 mA, inputs or Modbus
Preferred brand, if any, and the quantity

Why Rajkot Plants Choose RB Automation for VFDs

Offering two drive brands means a plant already built around Schneider can stay with Altivar, while a machine builder watching cost can use Frecon. Controllers, operator panels and transmitters for the same panel are available from us as well; read the Rajkot PLC guide and the industrial automation supplier in Rajkot page.

Conclusion

From a pump test bench in Metoda to a sand plant conveyor in a foundry, a drive sized on current and load type will cut power use, shield the motor and put speed under your control. Send RB Automation the nameplate and a line about what the motor drives, and we will suggest a Schneider or Frecon model for your Rajkot unit.

Looking for a quote in Rajkot? Contact RB Automation at +91 8511104864, WhatsApp +91 9898739737 or email contact@rbautomate.com. We call back Monday to Saturday, 10:00 am to 6:00 pm.

More Buying Guides for Rajkot

Frequently Asked Questions

Which AC drives do you supply to Rajkot?

We supply Schneider Electric Altivar low voltage and general purpose drives, and Frecon FR01, FR150A, FR500A, FR150T/FR500T and low power AC drives, from our base in Ahmedabad.

Can a VFD be used on a pump test bench?

Yes. A VFD lets the bench run the pump at different speeds and gives a soft start. Combined with pressure transmitters and a flow meter, it helps record the pump's performance at each speed.

Do you supply solar pump inverters?

Yes. The Frecon FR150T/FR500T is a solar water pump inverter with MPPT and dry-run protection. Share the pump motor rating and panel details so we can check the match.

Are you an authorised Schneider Electric partner?

Yes. RB Automation is an authorised Schneider Electric partner, and customers in Rajkot can order Altivar drives, Modicon PLCs and Harmony HMIs from us.

What is the price of a VFD in Rajkot?

There is no fixed price list. The price depends on the brand, power rating, supply, options and quantity. Use the form on this page, call +91 8511104864 or email contact@rbautomate.com for a quotation.
