Stepper Servo Drive Supplier in Rajkot: Buying Guide

Key Takeaways

Closed-loop stepper drives suit Rajkot CNC retrofits and feeders where one missed step scraps a part.
The drive compares encoder feedback with the command and raises an alarm if the axis cannot follow.
An open-loop axis can often be upgraded by changing only the motor and drive, keeping the PLC.
We supply the Rtelligent T42, T60 Plus, T86, T60S/T86S and DS86 to Rajkot from Ahmedabad.

Rajkot has a large base of older machines that are being upgraded rather than replaced: manual lathes turned into simple CNC machines, plasma tables given faster gantries, bar feeders added to existing turning centres. In many of these jobs the open-loop stepper is the weak link, because it can slip under load without anyone knowing. A closed-loop drive solves that while keeping costs below a full servo system. RB Automation is a stepper servo drive supplier in Rajkot for the Rtelligent closed-loop range, supplied from Ahmedabad, with help on choosing and wiring the drive by phone, WhatsApp and email.

Closed-Loop Stepper Jobs Around Rajkot

Machine tool and SPM builders in Aji GIDC, Bhaktinagar and on Gondal Road use closed-loop drives on CNC retrofits, plasma gantries and bar feeders. At Metoda GIDC and Shapar-Veraval, indexing tables and feeders that serve pump and engine component lines move to closed loop when a jammed part keeps putting them out of position. For many of these machines the controller and its pulse program stay as they are; only the motor, drive and encoder cable change.

How a Closed-Loop Stepper Drive Works

A stepper servo drive powers a stepper motor fitted with an encoder. The drive constantly checks where the encoder says the shaft is against where the command says it should be, and adds current to pull the axis back on track. If the gap grows beyond a set limit, the drive flags an alarm, and the machine can be stopped before it produces scrap. Because current follows the load instead of staying at maximum, the motor also stays at a lower temperature.

Rtelligent Closed-Loop Drives in Our Range

T42: pulse-command drive for small closed-loop motors on light axes.
T60 Plus: the mid-size option, widely used on feeders and SPM axes.
T86: for 86 mm motors on heavier axes.
T60S and T86S: the newer S series, with direct brake wiring and a phase-loss alarm.
DS86: a closed-loop drive with a digital display for 2-phase motors below 86 mm.

Pair each drive with Rtelligent closed-loop stepper motors, or with the brake and Z-signal encoder variants covered in the Rajkot stepper motor guide. Every model appears on our stepper servo drive overview.

Where Closed Loop Fits Between Stepper and Servo

An open-loop stepper is cheapest and is fine where the load never surprises you. A closed-loop stepper adds verification, an alarm and cooler running while staying almost as easy to set up. An AC servo is the step above for high speed, high inertia and continuous motion; our servo drive guide for Rajkot covers that end. The article stepper motor vs servo motor compares them in more depth.

Selecting a Stepper Servo Drive

Pick the closed-loop motor first; the drive size follows its frame and current.
Check the controller's pulse output type and signal voltage, or simply send us the PLC or CNC controller model.
Confirm the DC or AC supply available in the cabinet.
Plan to wire the alarm and in-position signals back to the controller.
On a vertical axis, choose a brake motor and connect the brake output.

Closed-Loop Drive Options Side by Side

Drive	Motor frame	Notable point	Rajkot use
T42	Small	Pulse-command closed loop	Light positioning, small feeders
T60 Plus	Mid size	Pulse-command closed loop	Bar and part feeders, SPM axes
T86	86 mm	Pulse-command closed loop	Heavier gantries and indexing tables
T60S / T86S	Mid to 86 mm	Direct brake wiring, phase-loss alarm	Vertical axes and retrofits
DS86	Below 86 mm	Digital display on the drive	Set-up and fault reading at the machine

Each product page lists current, voltage and encoder data, and we check the drive against your motor as part of the quotation.

A Typical Closed-Loop Application in Rajkot

Take a typical bar feeder added to an existing turning centre in a Bhaktinagar machine shop that turns bearing or auto part blanks. The feeder pushes a bar forward by a set length after each part is parted off. On an open-loop stepper, a bent bar or a sticky guide occasionally makes the pusher fall short; the next part is cut short and may only be caught at inspection. Changing the pusher axis to a closed-loop stepper motor with a T60 Plus drive keeps the same pulse signal from the feeder's controller, but now the drive works harder when the bar resists and signals an alarm if it still cannot reach the position. Wired to the turning centre's feed-hold input, that alarm stops the cycle before a bad part is made.

Common Mistakes with Closed-Loop Stepper Drives

Fitting the closed-loop drive but leaving its alarm output unconnected.
Crossing encoder cables between two axes during installation, which causes instant position errors.
Expecting a closed-loop stepper to match an AC servo on a fast, continuously running axis.
Choosing a brake motor and then not wiring the brake to the drive or PLC.

What to Send for a Stepper Servo Drive Quote

Details of the existing motor and drive, or else the axis load and speed
Controller model and its pulse output
Supply voltage available
Whether a brake or Z-signal encoder is needed
Number of axes and machines

Why Choose RB Automation for Rajkot

Drive and motor come from us as a matched Rtelligent pair, with a PLC too if the machine needs one, and our Ahmedabad team answers selection and wiring questions remotely. All product families are listed on our industrial automation supplier in Rajkot page.

Conclusion

When a Rajkot machine must never slip unnoticed yet runs well below servo speeds, a closed-loop stepper drive is usually the practical fix. Send RB Automation your motor, controller and load details and we will recommend a matched drive and motor.

Looking for a quote in Rajkot? Contact RB Automation at +91 8511104864, WhatsApp +91 9898739737 or email contact@rbautomate.com. We call back Monday to Saturday, 10:00 am to 6:00 pm.

More Buying Guides for Rajkot

Frequently Asked Questions

What is a stepper servo drive?

It is a closed-loop drive for a stepper motor fitted with an encoder. The drive checks the real shaft position against the command, corrects small errors and raises an alarm if the axis cannot keep up.

Which closed-loop stepper drives do you supply to Rajkot?

We supply the Rtelligent T42, T60 Plus and T86 pulse-control drives, the T60S and T86S S series and the DS86, together with matching closed-loop stepper motors, from our base in Ahmedabad.

Is a closed-loop stepper good enough for a CNC lathe retrofit?

It depends on the axis speed and load. Closed-loop steppers handle many slower retrofit axes and feeders well. For fast rapids or heavy, continuously moving axes an AC servo is usually better. Send the axis details and we will advise.

Do I need to change my PLC to move from open loop to closed loop?

Often not. In many machines the same pulse and direction output drives the closed-loop system, so only the motor, drive and encoder cable change. Share the controller model so we can check.

What is the price of a stepper servo drive in Rajkot?

There is no fixed price list. The price depends on the drive model, the matching motor and the order quantity. Use the form on this page, call +91 8511104864 or email contact@rbautomate.com for a quotation.
