Servo Drive Supplier in Delhi NCR: Buying Guide

Key Takeaways

R5 and R6 servo drives run draw and register axes on converting lines at Noida and Faridabad.
We supply Rtelligent R5, R6, S5L and S6L servo drives to Delhi NCR from Ahmedabad.
Select the drive by matched motor, supply voltage and control mode: pulse, analogue or fieldbus.
Earthing, shielded encoder cables and gain tuning decide how well the axis performs.

On a converting line in Noida or Faridabad, the servo drive is what keeps a draw roller in step with the printing unit and the rewinder. On a packaging machine from Okhla it times the sealing jaws to the film. For OEMs and plant engineers looking for a servo drive supplier in Delhi NCR, RB Automation supplies the Rtelligent AC servo drive range from Ahmedabad, matched to the motor and the controller.

Inside a Servo Drive

The drive runs three nested control loops for current, speed and position. It accepts a command as pulses, an analogue reference or a fieldbus message, reads the motor encoder constantly and adjusts current so the shaft follows. Gain settings decide how stiffly the axis holds position and how fast it responds; good tuning is what separates a smooth axis from a noisy one.

The Rtelligent Drive Line-Up

For mains-powered machines there are two families. The R5 series handles the bulk of general machine axes, and the R6 series is the pick when an axis is more demanding. For machines networked over RS-485 Modbus, the S5L and S6L series add position, speed and torque control. Between them they accept pulse, analogue and fieldbus commands. The AC servo drive page lists every model, and the motors that pair with them are in our servo motor guide for Delhi NCR.

Three Ways to Command the Axis

Pulse train

A PLC with fast outputs, for example the RX3U, sends a pulse per increment and a direction signal. It is easy to wire and debug, and it suits machines with a handful of axes.

Analogue reference

A voltage sets speed or torque. Converting lines use it for unwinds and rewinders, where the goal is steady tension rather than an exact position.

Network

One cable carries position targets, status and fault codes. With a motion controller like the RM500, many axes can be synchronised and diagnosed from the HMI.

Five Checks Before Ordering

Is the drive the correct partner for the motor's rating and encoder?
What does the panel provide: single-phase AC, three-phase AC or a DC bus for the S5L and S6L?
Which command method does your PLC or motion controller offer?
Which signals must be wired: overtravel limits, home, brake, ready and fault?
Will the axis brake hard or carry a vertical load, so that a braking resistor is needed?

Servo Drives in Delhi NCR Industry

Converting and printing lines in Noida and Faridabad use R5 and R6 drives for draw and register axes. Packaging machine builders in Okhla, Mayapuri and Wazirpur fit them on cartoners, flow wrappers and labellers. In the auto component belt of Udyog Vihar, IMT Manesar and Faridabad, servo drives run press feeders and assembly and test stations, while electronics plants in Noida use compact low-voltage drives on handling units. Wherever the drive goes, proper earthing, shielded encoder cable and patient tuning matter as much as the model.

Signs a Servo Drive Needs Replacing

Frequent over-current or encoder faults, overheating, or a discontinued model with no spares are the usual triggers. Our article signs it's time to replace your AC servo drive explains what to check. Send the old drive and motor nameplates and we can suggest an Rtelligent replacement pair.

Matching Drive and Command Method to NCR Machines

Machine	Drive family	Command method	Why
Draw and register axes on a Noida or Faridabad converting line	R5 or R6	Analogue or network	Steady speed and tension across the web
Cartoner or flow wrapper from Okhla or Wazirpur	R5 or R6	Pulse or network	Several axes timed to one machine cycle
Press feeder or test station in Manesar or Gurugram	R6	Pulse or network	Fast, repeatable moves every stroke
Compact handling unit in a Noida electronics plant	S5L or S6L	Pulse or network	RS-485 Modbus networking

Power ratings and interfaces differ by model; each product page lists them, and we confirm the motor-drive pair before you order.

A Typical Servo Drive Application in Delhi NCR

Consider a typical laminating and rewinding line in a Noida converting unit. An unwind, a draw roller and a rewinder must hold steady web tension while the line speed changes. The draw roller runs on an R6 drive in speed mode as the line master, and the rewinder drive runs in torque mode with its reference reduced as the roll diameter grows, so the tension stays even. Fault and ready signals from each drive go back to the PLC, so the line stops cleanly if any axis trips.

Why Servo Axes Misbehave

The axis hunts or buzzes because nobody tuned it after the load was mounted.
Random encoder faults appear because the encoder lead shares a tray with motor power cables.
Over-voltage trips on hard stops because there is no braking resistor.
An axis runs past its end stop because the limit switches were never wired.

Details That Speed Up a Servo Drive Quote

The motor you plan to use, or its power and encoder type
Available supply at the panel
Your PLC or motion controller and how it will command the axis
Signals to wire: limits, home, brake, fault
Number of axes per machine and where in the NCR the order is going

Why NCR Buyers Choose RB Automation for Servo Drives

We supply the Rtelligent drive, motor, cables, reducer and controller as one matched package. With no office in the NCR, our team answers selection and set-up questions by phone, WhatsApp and email, and orders ship from Ahmedabad. See the full range we supply to Delhi NCR.

Conclusion

The right servo drive matches the motor, the supply and the way your controller commands it. Send your motor and controller details to RB Automation for a matched Rtelligent recommendation supplied to Delhi NCR.

Looking for a quote in Delhi NCR? Contact RB Automation at +91 8511104864, WhatsApp +91 9898739737 or email contact@rbautomate.com. We call back Monday to Saturday, 10:00 am to 6:00 pm.

More Buying Guides for Delhi NCR

Frequently Asked Questions

Which servo drives do you supply to Delhi NCR?

We supply Rtelligent R5 and R6 series AC servo drives for general machines and the S5L and S6L series for low-voltage and compact builds.

Which control mode suits a converting or rewinding line?

Analogue speed or torque control is common for tension and winding, while fieldbus suits lines with several synchronised axes under a motion controller. Share the line layout and we will advise.

Can a servo drive run from my existing PLC?

Usually yes. A PLC with high-speed pulse outputs can command a servo in pulse mode, and a fieldbus controller can use a fieldbus drive. Tell us the PLC model to check.

Can you suggest a replacement for an old servo drive?

Yes. Send nameplate photos of the drive and motor on WhatsApp at +91 9898739737 and we will suggest a matching Rtelligent drive and, if needed, motor.

What is the price of a servo drive in Delhi NCR?

The price depends on the drive series, power, control mode, matching motor and quantity, so RB Automation quotes each requirement. Use the form on this page, call +91 8511104864 or email contact@rbautomate.com.
