Servo Drive Supplier in Hyderabad: Buying Guide

Key Takeaways

R6 and S6L drives suit Hyderabad cartoners and tube fillers where speed changes with the batch recipe.
We supply Rtelligent R5, R6, S5L and S6L AC servo drives to Hyderabad from our Ahmedabad base.
The R6 offers STO and EtherCAT, Profinet, CANopen or Modbus options; the S5L and S6L offer RS-485 Modbus.
Tuning, earthing and encoder cable routing decide axis performance as much as the drive model.

A modern cartoner or tube filler built in Hyderabad may run a dozen different products, each with its own carton size, fill volume and speed. Instead of changing cams and gears for every batch, the machine loads a recipe and the servo drives change the motion. RB Automation is a servo drive supplier in Hyderabad for these machines, shipping the Rtelligent AC servo drive range and matched motors from Ahmedabad and supporting selection by phone, WhatsApp and email.

Inside a Servo Drive

The drive is where the servo axis is actually controlled. It receives a command, whether a pulse train, an analogue reference or a fieldbus message, reads the motor's encoder thousands of times a second, and regulates current so the motor follows the commanded position and speed. Gain settings decide how stiff the axis is and how quickly it settles. Safety functions, overload protection and alarm outputs also live here.

The Rtelligent Drives Available in Hyderabad

R5 series: general purpose AC servo drives for everyday machine axes.
R6 series: built on an ARM and FPGA platform with Rtelligent's R-AI 2.0 algorithm, safe torque off (STO), analogue control and EtherCAT, Profinet, CANopen or Modbus options.
S5L series: for motors from 50 W to 2 kW, with RS-485 Modbus and position, speed and torque control.
S6L series: for motors from 100 W to 2 kW, with RS-485 Modbus networking and position, speed and torque control.

The AC servo drive overview lists every model; motors to pair with them are in the Hyderabad servo motor guide.

How the Drive Takes Orders

Pulse and direction: the easiest hook-up when the PLC has fast transistor outputs, for example the RX3U or the 8-axis RX8U.
Analogue reference: the PLC sends a variable setpoint, handy where foil or film tension must be held.
Modbus over RS-485: the PLC or HMI writes speeds, positions and recipes and reads alarms.
EtherCAT and other fieldbuses: one cable carries commands and diagnostics for many axes, with an RM500 acting as the master.

Servo Drives Across Hyderabad's Industry

Pharma machinery builders in Kukatpally, Cherlapally, Uppal and Nacharam use R6 and S6L drives on cartoners, tube fillers, labellers and blister lines, where recipe-driven speed changes matter. Formulation plants in Patancheru, Bollaram and Genome Valley replace drives on existing machines and often want a modern drive that accepts the same pulse command. Engineering units near Balanagar and Adibatla use servo drives in test rigs and assembly fixtures. In each case the details of installation, from shielded encoder cables to proper earthing, decide whether the axis runs quietly.

Selecting the Drive

Begin with the motor, since its power and encoder type fix the drive size.
Confirm the supply available in the panel.
Pick a command method the controller already offers.
List the I/O: limits, home sensor, brake output, alarm and in-position signals.
Decide whether STO is needed for the machine's safety concept.
Allow for regenerated energy on fast-stopping or vertical axes with a braking resistor.

Signs an Existing Drive Needs Replacing

Frequent overcurrent or encoder alarms, overheating and an obsolete model with no spares are the usual triggers. The warning signs are covered in more depth in when to replace an AC servo drive.

Rtelligent Servo Drives Side by Side

Series	Highlights	Typical machine
R5	General purpose AC servo drive	Everyday machine axes
R6	ARM + FPGA, R-AI 2.0, STO, EtherCAT, Profinet, CANopen or Modbus options	Cartoners, tube fillers, multi-axis lines
S5L	50 W to 2 kW motors, RS-485 Modbus, position, speed and torque control	Compact machines with Modbus HMIs
S6L	100 W to 2 kW motors, RS-485 Modbus, position, speed and torque control	Recipe-driven packaging machines

Exact ratings and interfaces are listed on each product page; we confirm the motor and drive pairing before dispatch.

Command Methods Compared

Method	Wiring	Suits
Pulse and direction	Two signals per axis from the PLC	Machines with a few axes and a pulse-type PLC
Analogue	Variable setpoint signal	Holding foil or film tension
RS-485 Modbus	Daisy-chained serial link	Recipe parameters and alarms from an HMI
EtherCAT	One Ethernet cable through all axes	Multi-axis synchronised machines

A Typical Servo Drive Application in Hyderabad

Take a typical tube filling and sealing machine built in Nacharam for an ointment line. The tube holder turret, the filling pump piston and the tube lift must move in step, and each product has its own fill volume and speed. With the filling axis on an S6L drive linked by Modbus, the HMI writes the new stroke and speed for each recipe, and the drive reports alarms back to the PLC. On a larger version with several synchronised axes, R6 drives on EtherCAT under an RM500 controller remove most of the point-to-point wiring, and STO can be used as part of the guard door safety circuit.

Servo Drive Errors Seen on Packaging Machines

Running a heavy turret on untuned, out-of-the-box gains.
Encoder leads without a shield, or a poor panel earth, producing random encoder faults.
Fast-stopping or load-lowering axes with nowhere to dump regenerated energy.
Treating STO as an afterthought instead of part of the safety design.

Details We Need to Quote a Servo Drive

The motor it will run, or its power and encoder type
Supply voltage in the panel
Which controller will command it, and how
I/O and safety needs, including STO
Quantity

Why Choose RB Automation for Servo Drives

Hyderabad OEMs can take the drive, motor, cables, gearbox and controller from a single Rtelligent source instead of piecing an axis together from several vendors. Selection and set-up questions are answered by phone, WhatsApp and email, and the dispatch date is confirmed with the quotation. See every product family on the Hyderabad automation supplier page.

Conclusion

A servo drive chosen around its motor, the panel supply and the machine's command method turns a recipe change into a few seconds on the HMI. Send RB Automation the motor model and the controller you use, and we will recommend an R5, R6, S5L or S6L drive for your Hyderabad machine.

Looking for a quote in Hyderabad? Contact RB Automation at +91 8511104864, WhatsApp +91 9898739737 or email contact@rbautomate.com. We call back Monday to Saturday, 10:00 am to 6:00 pm.

More Buying Guides for Hyderabad

Frequently Asked Questions

Which servo drives do you supply to Hyderabad?

We supply Rtelligent R5 and R6 series AC servo drives and the S5L and S6L series, together with matched servo motors, cables and reducers, shipped from our Ahmedabad base.

Which servo drive suits a cartoner or tube filler?

The R6 and S6L are common choices where speeds change with the batch recipe. The R6 offers fieldbus options such as EtherCAT, Profinet, CANopen or Modbus, and the S6L offers RS-485 Modbus with position, speed and torque control.

Does the R6 series support safe torque off?

Yes. The R6 series includes STO (safe torque off). Tell us the machine's safety requirements so we can confirm the right configuration.

Can the drive work with my existing PLC?

Usually yes. A PLC with high-speed pulse outputs can command the drive in pulse mode, and a Modbus or fieldbus PLC can use the network options. Share the PLC model and we will check.

What is the price of a servo drive in Hyderabad?

There is no fixed price list. The price depends on the drive series, power, control option, matching motor and quantity. Use the form on this page, call +91 8511104864 or email contact@rbautomate.com for a quotation.
