Servo Motor Supplier in Hyderabad: Buying Guide

Key Takeaways

Servo motors drive the tablet, capsule and packaging machines and other pharma equipment built in Hyderabad.
We supply Rtelligent RSHA, RSNA, RSDA and RSM AC servo motors, integrated and DC servos and servo reducers.
Size the motor from the motion profile: peak and RMS torque, top speed and load inertia ratio.
Washdown areas may call for motors with higher IP ratings, offered on selected RSNA models.

Hyderabad does not only use pharma machines, it builds them. Workshops in Kukatpally, Cherlapally, Uppal and Nacharam make tablet presses' feeders, capsule handling units, cartoners, blister lines and inspection machines for plants across India. As these machines get faster and handle more format changes, servo motors replace cams and mechanical drives. RB Automation is a servo motor supplier in Hyderabad for these builders and for plant maintenance teams, shipping the Rtelligent servo range with matched drives from Ahmedabad and helping with sizing by phone, WhatsApp and email.

What Sets a Servo Motor Apart

A servo motor carries a high-resolution encoder and works with a drive that closes position, speed and current loops continuously. When the load changes, for example as a hopper empties or a format part is swapped, the drive raises or trims current so the motion stays on profile. The result is quick acceleration, high speed, the ability to ride through brief overloads and precise stops, which are exactly what electronic camming and format changeovers need.

Rtelligent Servo Motors We Supply

RSHA series: AC servo motors in 60 and 80 mm frames with 17-bit magnetic or 23-bit optical absolute encoders and an optional brake.
RSNA series: AC servo motors with the same encoder choices, an optional brake and IP65/IP66 options.
RSDA series: ultra-short body AC servo motors for machines where length is tight.
RSM series servo motors.
IDV integrated low-voltage servo: motor and drive in one body on an 18-48 VDC supply, with RS-485 or CANopen control.
Super short DC servo motor: 48 V motors with an optional brake.
Servo reducers: planetary gearboxes in several sizes to raise torque and balance inertia.

Across these AC series, power ratings run from about 50 W up to 1 kW, enough for most pharma packaging and handling axes. Details are on the AC servo motor overview, and complete motor-drive sets under servo systems.

Servo Axes on Pharma Equipment

Tablet and capsule handling

Feeders, rejection gates, counting heads and transfer star wheels use servo motors where the timing must follow the machine's master speed.

Cartoners and blister lines

Carton feeding, product pushers, foil index and cutting stations use servos so that a format change becomes a recipe change on the HMI instead of a mechanical adjustment.

Inspection and serialisation

Track-and-trace and vision inspection modules need smooth, accurately spaced product transport, which servos provide.

Engineering and aerospace suppliers near Adibatla

Test benches, positioning fixtures and small automation cells use servo axes where load and speed vary.

A Sizing Routine That Works

Write down the move: stroke length, move time, ramp and pause for each step of the cycle.
Calculate torque: peak torque during acceleration and the RMS value over the full cycle, including friction and any gravity load.
Check speed: top motor speed, after any reduction ratio.
Balance inertia: heavy star wheels and format parts may need a reducer to keep the inertia ratio reasonable.
Consider the environment: washdown areas may need a higher IP rating, and any axis that carries weight needs a brake.
Pair the drive: only a drive from the paired series should run the motor; see the servo drive guide for Hyderabad.

When a Stepper Is Enough

Slow indexing and short positioning moves can often be handled by a closed-loop stepper at lower cost. See the stepper servo drive guide for Hyderabad and our comparison of stepper motor vs servo motor.

Servo Motor Choices Compared

Option	Key points	Where it fits
RSHA series	60/80 mm frames, absolute encoder, optional brake	General packaging and handling axes
RSNA series	50 W to 1 kW, optional brake, IP65/IP66 options	Axes in areas that see cleaning
RSDA series	Ultra-short body, 60/80 mm frames	Machines with little room behind the motor
IDV integrated low-voltage servo	Drive built in, 18-48 VDC, RS-485 or CANopen	Compact and mobile equipment
Super short DC servo	48 V, optional brake	Tight spaces and Z-axes
Servo reducer	Planetary gearbox	Heavy star wheels and inertia matching

Servo or Closed-Loop Stepper for Pharma Machines

Question	Servo motor	Closed-loop stepper
Continuous synchronised motion at speed?	Yes, designed for it	Limited
Frequent format changes via recipe?	Handles easily	Possible on slower axes
Short-term overload capacity	High	Low
Commissioning effort	Tuning needed	Minimal
Typical spend per axis	More	Less

A Typical Servo Application in Hyderabad

Imagine a typical horizontal cartoner built by an Uppal machinery workshop for a blister line. Blister strips arrive from the packer, a pusher loads them with a leaflet into a carton, flaps are folded and the batch code is printed. The carton magazine pick, the product pusher and the main chain must stay locked together at every speed, and a format change for a different carton size should take minutes. Servo motors on the pusher and the carton feed, with a servo reducer on the heavier chain axis to balance inertia, let the controller hold the timing electronically. A closed-loop stepper can take care of the slow leaflet feeder to keep the machine's cost in check.

Servo Sizing Errors to Avoid

Sizing on continuous torque and ignoring the acceleration peak.
A high inertia ratio on heavy change parts without a reducer.
Pick-and-place heads that rise and fall but have no holding brake.
Running encoder cables beside motor power cables.
Combining a motor and drive that are not a matched pair.

Information for a Servo Motor Enquiry

Motion profile: stroke, time and dwell
Load mass or inertia, and any gearbox ratio
Top speed and duty cycle
Brake, encoder and IP rating needs
Controller in use and quantity

Why Hyderabad OEMs Choose RB Automation

Motor, drive, cables and gearbox all come from Rtelligent through us, its technical partner, so every machine in a series is built with an identical, matched axis. Sizing questions are handled by phone, WhatsApp and email, and the dispatch date is confirmed with the quotation. Other families for the city, from PLCs to transmitters, are on our Hyderabad automation supplier page.

Conclusion

For the tablet, capsule and packaging machines built and run in Hyderabad, a properly sized servo motor gives speed, accuracy and quick format changes. Send RB Automation the stroke, timing and load of each axis and we will propose a Rtelligent motor, drive and gearbox that belong together.

Looking for a quote in Hyderabad? Contact RB Automation at +91 8511104864, WhatsApp +91 9898739737 or email contact@rbautomate.com. We call back Monday to Saturday, 10:00 am to 6:00 pm.

More Buying Guides for Hyderabad

Frequently Asked Questions

Which servo motors do you supply to Hyderabad?

We supply Rtelligent RSHA, RSNA, RSDA and RSM series AC servo motors, the IDV integrated low-voltage servo motor, super short DC servo motors and servo reducers, shipped from our Ahmedabad base.

Are your servo motors suitable for pharma packaging machines?

Yes. They are used on feeders, cartoners, blister lines and inspection machines. Selected RSNA models have IP65/IP66 options for areas that see cleaning; tell us the environment so we can check.

How should I size a servo motor for a cartoner axis?

Start from the motion profile, then calculate peak and RMS torque, top speed and the load inertia ratio. Share these, or the motor you are replacing, and we will recommend a matched motor, drive and reducer.

Do you supply the drive and gearbox with the motor?

Yes. We supply matched Rtelligent servo drives, cables and servo reducers along with the motor.

What is the price of a servo motor in Hyderabad?

There is no fixed price list. The price depends on the series, power, encoder, brake, matching drive and quantity. Use the form on this page, call +91 8511104864 or email contact@rbautomate.com for a quotation.
